Punched guardrails

Punched Guardrail Systems - Standard Technical Parameters
1. Structural Dimensions
Parameter Metric Range Imperial Range
Panel Height Under 1.2 meters (Under47")
Standard Panel Length 2000mm / 2440mm / 3000mm (78" / 96" / 118")Post Spacing 1000mm - 4000mm (39" - 157")
Material Thickness 0.5mm - 3.0mm
Perforation Diameter Ø5mm - Ø50mm (Ø0.19" - Ø2")
2. Critical Safety Performance
Impact Resistance:
≥50 kJ/m (EN 1317-2 N2/H2 level)
MASH TL-3 compliant (US Federal Std.)
Open Area Ratio: 30% - 60% (±3%)
Deflection Limit: ≤100mm (at 100 kN load per EN 1991-1-1)
3. Material & Certification
Component Specification
Guardrail Panel S355JR steel (EN 10025) / 6063-T6 aluminum
Posts Ø76mm/Ø89mm CHS (JIS G3444)
Surface Finish Hot-dip galvanizing (550g/m² per ISO 1461)
Certifications CE Marking (EU) / AASHTO M180 (US) / AS 3845 (AU)
4. Installation Parameters
Foundation Type:
Direct burial: 600mm depth (soil class II)
Flange base: M24 anchor bolts (8.8 grade)
Connection System: Anti-tamper bolts (ISO 7380) / Welded option
