Product Description:
Jintong’s minimal-intervention wall facade system is a modular solution for heritage, semi-historic, or adaptive reuse buildings where preserving the original architectural character is essential. It integrates metal sunshade panels with micro-perforated vent panels to provide solar shading, passive ventilation, and moisture control without structural intrusion. The system is fully reversible, factory-fabricated, and designed to clip onto existing masonry joints — avoiding drilling into load-bearing walls. This approach enhances thermal performance, reduces interior humidity and solar heat gain, and lowers energy demand, while maintaining the aesthetic integrity of historic facades.

Product Attributes:

• Material: Aluminium panels with powder-coated matte bronze finish for heritage color matching

• Sunshade Blades: 75 mm projection for glare control and solar shading

• Vent Panels: Micro-perforated 1 mm, forming pressure-equalized air cavities

• Airflow Gap: 40–50 mm ventilated cavity between wall and panel for controlled convection

• Installation: Modular clip-on system; reversible without penetrating structural masonry

• Performance Benefits:

• Facade surface temperature drop: 19 °C average

• Internal air temperature reduction: 5.8 °C

• Moisture ingress reduced by 70 %

• Daylight management and 12 % reduction in lighting energy

• Applications: Heritage buildings, adaptive reuse projects, semi-historic administrative blocks
